    Customized PPR Fiberglass Plastic Pipe, Reliable Safe Plastic Hot Water Pipe

    Product Details:

    Place of Origin: Zhejiang China
    Brand Name: DSTHERM
    Certification: ISO9001 CE
    Model Number: 20-160mm

    Payment & Shipping Terms:

    Minimum Order Quantity: Negotiation
    Price: Negotiation
    Packaging Details: 4m per piece by poly bag/nylon bag
    Delivery Time: 10 days
    Supply Ability: 10 days /40 feet container
    Get Best Price Contact Now

    Detail Information

    Product Name: PPR Pipe Color: Green/Grey/White/Blue/Customized
    Size: 20-160mm Standard: Din 8077-8078
    Application: Cold Or Hot Water Supply Brand Name: DSTHERM Or OEM
    Service Life: 50 Years Under Normal Condition Specification: PN12.5/PN16/PN20/PN25
    Available Pipe Series: S2.5;S3.2;S4;S5 OEM&ODM: Available
    Material: R200P/Customized Package: Packed By Nylon Bag/Customized
    Logo: DSTHERM/Customized
    High Light:

    ppr plastic water pipe

    ,

    ppr plastic pipe

    Product Description

    Customized PPR Fiberglass Plastic Pipe, Reliable Safe Plastic Hot Water Pipe

    ISO9001 PPR Pipe DIN8077/8078 Polypropylene 20-160mm Length 4M, 6M, or Customize



    Material: PPR

    size: 20-160mm

    Pressure Rating: PN1.25,PN1.6,PN2.0,PN2.5

    Colour: green ,light grey, white or other colors on request
    Connection:socket fusion joint,electro fusion joint or transition joint
    Standard: din 8077-8078

    Production temperature:-45 to +95 degree cesius



    Parameters of the PPR Pipe SDR11/S5/PN10
    Nominal Outer Diameter Diameter Wall Thickness Inner Diameter
    20 20 2.0 16.0
    25 25 2.3 20.4
    32 32 2.9 26.2
    40 40 3.7 32.6
    50 50 4.6 40.8
    63 63 5.8 51.4
    75 75 6.8 61.4
    90 90 8.2 73.6
    110 110 10 90.0
    160 160 14.6 130.8

    Parameters of the PPR Pipe SDR9/S4/PN12.5
    Nominal Outer Diameter Diameter Wall Thickness Inner Diameter
    20 20 2.3 15.4
    25 25 2.8 19.4
    32 32 3.6 24.8
    40 40 4.5 31.0
    50 50 5.6 38.8
    63 63 7.1 48.8
    75 75 8.4 58.2
    90 90 10.1 69.8
    110 110 12.3 85.4
    160 160 17.9 124.2






    Applications

    1) Cold and hot water supply systems for civil and industrial constructions, e.g. in

    residential buildings, hospitals, hotels, school and office buildings, ship building

    2) Drinking water systems and food industry pipe works

    3) Central air conditioning system

    4) Irrigating system for gardens and green houses

    5) Public and sport facilities such as swimming pools and stadiums

    6) For rainwater utilization systems





    Advantage
    1. Sanitary, non-toxic, no heavy metal additives, directly apply to the water supply system.
    2. Heat insulation and Saving Energy: low thermal conductivity which is only 1/1500 of brass pipe, and 1/250 of steel pipe.
    Non-toxic: no heavy metal additives would not be covered with dirty or contaminated by bacterium.
    3. Light weight, high strength and high impact strength.
    4. Lower Installation Costs: light weight and good hot-melt performance can reduce installation costs by as much as 50% over metal piping system.
    5. Convenient installation, reliable, recycled, environmental protection and safe.
    6. Corrosion Resistant: resist chemical matters or electron chemical corrosion.

    7 High Temperature Resistance: the maximum sustained working temperature is up to 70 Degrees Celsius, the maximum transient temperature is up to 95 Degrees Celsius.

    8.Higher Flow Capacity: smooth interior walls result in lower pressure loss and higher volume than metal pipes.

    9. Long service life: more than fifty years under the normal pressure and temperature.





    Payment term :LC ,TT .

    Delivery time : 20days /20 feet container , 35days/40 HQ

    Samples lead time: 3-7 days

    MOQ: 100-4000pcs

    Package: pcs/polybag, 4 meters/tube or as client's request
